PIONEER Carrozzeria DEX-P01 + DEQ-P01

เครื่องสภาพดี ฟรอนท์เกรดสูง มีครบ ตัวฟรอนท์+โปรเซสเซอร์+สายออฟติก รีโมท ครบ

รุ่นสูง ชิป DAC PCM1704 ตัวท็อป ให้เสียงดีมาก ต่อไอพ็อด+บลูทูธได้ผ่านกล่อง มีขายแยกครับ


General

Power source .......... 14.4 V DC (10.8 – 15.1 V allowable)

Grounding system ........................................ Negative type

Max. current consumption ........................................ 4.0 A

Dimensions

(mounting size) ...... 178 (W) × 50 (H) × 160 (D) mm

(front face) .............. 188 (W) × 58 (H) × 20 (D) mm

Weight ...................................................................... 1.7 kg

Maximum preout output level .................................. 4.0 V

Preout impedance .................................................... 100 Ω

Tone controls

(Bass)

Frequency .................................................. 100 Hz

Gain .............................................................. ±8 dB

(Treble)

Frequency .................................................. 10 kHz

Gain .............................................................. ±8 dB

Digital input .................................................. Optical input

Sampling frequency .................................... 44.1 – 96 kHz

Digital output .............................................. Optical output

CD player

System .................................... Compact disc audio system

Usable discs .................................................. Compact disc

Signal format .................... Sampling frequency: 44.1 kHz

Number of quantization bits: 16; linear

Frequency characteristics .............. 5 – 20,000 Hz (±1 dB)

Signal-to-noise ratio .... 107 dB (1 kHz) (IEC-A network)

Dynamic range ............................................ 98 dB (1 kHz)

Number of channel .............................................. 2 (stereo)

FM tuner

Frequency range ......................................   MHz

Usable sensitivity ...................................................... 9 dBf

(0.8 µV/75 Ω, mono, S/N: 30 dB)

50 dB quieting sensitivity .... 15 dBf (1.5 µV/75 Ω, mono)

Signal-to-noise ratio ...................... 70 dB (IEC-A network)

Distortion .......................... 0.3% (at 65 dBf, 1 kHz, stereo)

Frequency response ...................... 30 – 15,000 Hz (±3 dB)

Stereo separation .......................... 40 dB (at 65 dBf, 1 kHz)

MW tuner

Frequency range ........................ 531 – 1,602 kHz (9 kHz)

Usable sensitivity .............................. 18 µV (S/N: 20 dB)

Selectivity .................................................. 50 dB (±9 kHz)

LW tuner

Frequency range ........................................ 153 – 281 kHz

Usable sensitivity .............................. 30 µV (S/N: 20 dB)

Selectivity .................................................. 50 dB (±9 kHz)
